Capability



We Offer a Full Range of Printed Circuit Board Capabilities to Fit All of Your PCB/FPC Needs

As a professional Printed Circuit Board manufacturer, Headpcb fabricates a complete line of PCB/FPC products and services in-house from prototype manufacturing to high volume mass production.

In order for us to keep our products and services competitive, we constantly are updating our equipments to better serve our customers. Please send email to sales@headpcb.com if your boards are beyond the capabilities listed below.

Item Manufacturing Capability
Number of Layers 1-30 Layer
Material CEM-1,FR-4,Aluminum Based,Copper based,High frequency plate,
Heavy copper,BT,Rogers,PTFE ect
Maxmum Size 600x1000 mm
Tolerance(Outline) ±0.13mm(for CNC)/±0.4mm(for V-cut)
Board Thickness 0.2-6.0mm
Board Thickness Tolerance(t≥1.0mm) ±10%
Aspect Ratio 10:1
Min Trace 0.075mm/3mil
Min Spacing 0.075mm/3mil
Outer Layer Copper Thickness 1-6 oz
Inner Layer Copper Thickness 0.5-6 oz
Drill Sizes (CNC) 0.2-6.3mm
Min Width of Annular Ring 0.15mm(6mil)
Finished Hole Diameter (CNC) 0.2mm-6.2mm
Finished Hole Size Tolerance(CNC) ±0.075mm
Minimum Character Width(Legend) 0.15mm
Minimum Character Height (Legend) 0.8mm
Character Width to Height Ratio (Legend) 1:5
Minimum Diameter of Plated Half Holes 0.6mm
Surface Finishing HASL lead free
Immersion gold
Hard plating gold
Carbon ink
Solder Mask Green ,Red, Yellow, Blue, White ,Black
Silkscreen White, Black, None
Panelization V-scoring,Tab-routing,Tab-routing with Perforation (Stamp Holes)
